best wood KVH Our solid structural timber

Solid structural timber - KVH® for short - is the material for modern timber constructions made of finger-jointed spruce.

Because safety is particularly important with KVH®, we pay special attention to quality. That is why we are also a member of the KVH® monitoring association with constant neutral monitoring by the MPA Stuttgart.

As KVH® sleepers, Douglas fir finger-jointed NSI, it is ideal for building balconies, terraces, bridges and much more.

best wood KVH Fichte
  • C24

    Strength class

Fields of application

  • Roof
  • Ceiling
  • Wall
  • Floor

Delivery formats

  • Type of wood

    • Spruce
    • Douglas
  • Cross section

    • Rectangular solid
    • Rectangular glued
    • Wedge-shaped
  • Composite

    • Finger-jointed
    • not finger-jointed
Thickness (mm)
45 50 60 80 100 120 140 160
60
80
100
120
140
145
160
180
200
220
240
260
280
Width (mm)
with finger joints, spruce, industrial quality, with finger joints, Douglas fir, industrial quality
Purch. in pack. Length 5.00–14.00 m
Single pieces 13.00 m (entire beams), 6.50 m (half beams)
KVH® as per list Length 5.00–14.00 m lengths under 5.00 m are available in multiple lengths
Fixed size ± 2,00 mm Length 2.30–5.00 m; min. 40 pieces / one dimension – one length; Length 5.00–14.00 m – single pieces possible
Douglas fir KVH single pieces Length 13.00 m
Other cross sections Available on request
without finger joints, spruce, NSI
Purch. in pack. Length 5.00 m
Single pieces Length 5.00 m
Scantling made from KVH separated into 30/50 mm

Technical data

StandardEN 15497:2014
Strength classC24
Application classesUse in application classes 1 and 2 according to EN 1995-1-1
DryingKiln dried, wood moisture max. 18 % at delivery
General informationFinger-jointed, planed on four sides (levelled), chamfered 4 mm (measured diagonally)

Quality

For your and our safety, we take great care to ensure a high standard of quality.

Accessories

Suitable accessories

Find everything that is right and good for working and processing our timber products.
